COMMISSIONING
246 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
mechanisms must be enabled. However, under certain circumstances,
they can or need to be disabled (refer to section 9.5)
Entity name Entity name
(SmartView)
Default
Value
Description
[Wire tension
protection]
[Wire tension
pr]
(Product level)
Enable
Enables/disables the wire-protection. The motor is
stopped from moving in the wrong direction when the
wire tension gets too low or too high. This protects the
wire getting out of the drum or from breaking.
If the tension is outside the allowable range for more
than 30s an error is generated. The gauge however is
still operational.
[Wire rupture
protection]
[Wire rupture
pr]
(Product level)
Enable
Enables/disables the wire-rupture-protection. In case the
wire protection mechanism detects a low wire tension
error (see above) a wire rupture error is generated. The
gauge is no longer operational until a board reset is
given.
Note: the wire tension protection also needs to be
enabled.
[Drum slip detection]
-
Enable
Enables/disables drum slip detection.
If excessive force is applied to the displacer/wire, the
inner and outer magnet may slip, causing level jumps of
1/3
rd
of the drum circumference (~0.11 m).
A detected drum slip results in a ‘Drum slip occurred’
error (6162 on the SmartView). This error can only be
cleared by entering maintenance mode (refer to section
11.1).
[Drum slip
occurrence
-
-
Number of detected drum slips since last initialization of
the non-volatile ram.
[Motor position
errors]
[Motor pos
errors]
(Displ. Level)
Number of detected motor errors since last reset. The
default value will be 1, because the motor position is
always checked at start-up.
