36 User Guide Integrated Lights-Out

Static Route #1, #2, and #3 (destination gateway)—Assigns the appropriate

static route destination and gateway IP address on your network (the default IP

values are 0.0.0.0 and 0.0.0.0, where the first IP address corresponds to the

destination IP, and the second IP address corresponds to the gateway IP).

Enable iLO IP Address Assignment

The bay #1 through bay #16 checkboxes allow you to select which BL p-Class

blade servers will be configured. You can Enable All, Clear All, or Apply your

selection.

RIBCL RACK_INFO Commands

Several new XML commands have been added to the RIBCL structure to support

reading and writing of Static IP Bay Configuration in scripting. The new RIBCL

commands must be scripted within a RACK_INFO (on page 310

) command

block. The new attributes are:

•

MOD_ENCLOSURE_IP_SETTINGS—Modifies the Static IP Bay

Configuration settings. This command is only valid inside a RACK_INFO

block. The logged-in user must have the configure iLO privilege. This

attribute must appear inside the RACK_INFO command block with MODE

= "write."

BAY_ENABLEMASK—Enables the use of Static IP Bay Configuration

addressing. The attribute MASK is a 16-bit number. Each bit represents a

slot in the enclosure. If the bit is set, that particular slot is assigned to use the

Static IP Bay Configuration settings. The LSB represents slot 1. For

example, the MASK="0x0001" only allows slot 1 to use Static IP Bay

Configuration. This number can be either a hexadecimal number or a decimal

number. This command must appear inside the

MOD_ENCLOSURE_IP_SETTINGS block.

ENCLOSURE_IP_ENABLE—Enables or disables the use of Static IP Bay

Configuration. This attribute must appear inside the

MOD_NETWORK_SETTINGS command block. The possible values are

"Y" or "N." It is case-insensitive. This attribute is only applicable on blade

servers.
