Using iLO 47

• SMBIOS data such as host platform, system ROM, processors, embedded

MAC addresses, expansion slots, and memory modules present at POST

iLO Event Log

The iLO Event Log is a record of significant events detected by iLO. Logged

events include major server events, such as a server power outage or a server

reset; and iLO events, such as an unauthorized login attempt.
