Procedure
Step 1 Add a UPS2000G-L.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add a UPS2000G-L.
Table 5-6 Adding a UPS2000G-L
Path Parameter Setting
Choose
System
Settings >
Device
Management
and click Add
Device. The
parameters
for adding
devices are
displayed.
Device
attribute
Select UPS from the drop-down list box.
Device Type Select UPS2000G-L from the drop-down
list box.
Connect To Select ECC800 from the drop-down list
box.
Communicati
ons Port
Select COM4 from the drop-down list box.
NOTE
The setting example indicates that the
UPS2000G is connected to the COM4 port on
the ECC800-Pro. If the UPS2000G is connected
to another port, enter the number of the
connected port.
Device
Address
In this example, Device Address is set to 1.
During actual conguration, set the device
address for the UPS2000G-L based on the
actual situation.
3. Click Test Connect to check whether the UPS2000G-L connects to the
ECC800-Pro properly.
– If the connection succeeds, click
Conrm. The connected devices are
displayed in the Number of connected devices list.
– If the connection fails, check whether the device is properly connected to
the ECC800-Pro, whether the device and ECC800-Pro are running
properly, and whether the parameter settings are consistent with the
device parameters.
----End
5.3.7 Commissioning Sensors
5.3.7.1 Setting and Adding a Smoke Detector (Connected to an AI/DI Port on
the ECC800-Pro)
If a smoke detector is installed, perform the following steps to
congure it.
Context
If the detector is prefabricated, only check its settings.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 5 Power-On Commissioning
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 119
