If the PAD screen needs to remain on for a long time during usage, adjust the
brightness to below 80%.
----End
4.2.6.3 Installing Remote T/H Sensors for the Smart Cooling Product
Procedure
Step 1 Install T/H sensors.
1. Open the front and rear doors of the cabinet.
2. Unpack the two T/H sensors, and attach one to the 33 U position on the right
post of the front door and the other to the 11 U position on the right post of
the rear door of the cabinet.
The installation positions of the T/H sensors can be adjusted as required.
Step 2 Set the DIP switch address of the T/H sensor on the front door to 2 and that of
the T/H sensor on the rear door to 1.
Table 4-5 DIP switch settings on T/H sensors
Address
DIP Switch Sequence No.
1 2 3 4 5 6
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
The default address of T/H sensors purchased from Huawei is 1.
Step 3 Insert the pre-routed cables into the ports on the T/H sensors on the front and
rear doors.
----End
4.2.6.4 Installing T/H Sensors
Procedure
Step 1 Install T/H sensors.
1. Open the front and rear doors of the cabinet.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 4 Installation Guide
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 75
