You can adjust the shape of Room, Room–ShapeNode, Building–ShapeNode, Floor–
ShapeNode, Container–ShapeNode, and NetecoSite by:
1. Hold down Shift and click the frame to add a yellow dot.
2. Click and move the yellow dot to design an irregular polygon.
3. To delete a management domain, click the domain icon and select Delete under .
Step 5 In the right side of the view area, set Management Info.
You can congure Management Info, Electricity Info, and Refrigeration Info for the
equipment room management domain.
Step 6 Click
on the toolbar to save the settings.
Step 7 Repeat steps Step 3 to Step 6 until the conguration is complete.
----End
5.3.11.1.8 Example: Adding a Smart Module
This section describes how to create a module in the root node, subnet, equipment
room, container, or site management domain.
Prerequisites
You have created management domains in Planning
Conguration.
Procedure
Step 1 Log in to the NetEco client.
Step 2 On the main menu, choose Device Management >
Conguration > Planning
Conguration.
Step 3 Choose the management domain where you want to add a smart module from
the navigation tree on the left.
Step 4 In the Domain area on the lower left of the page, select Modular from the drop-
down list box.
Step 5 Select the Modular to be added and drag the modular icon to the management
domain area.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 5 Power-On Commissioning
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 144
