Figure 4-23 Routing a signal cable
----End
4.2.6.6 (Optional) Installing a Server
Procedure
Step 1 Determine the installation position of the server and check whether
oating nuts
are installed. If not, install them rst.
Figure 4-24 Installing a oating nut
Step 2 Install guide rails.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 4 Installation Guide
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 77
