Huawei FusionModule500 Smart User Manual

Item Specications
Dimensions (H x W x
D)
131 mm x 438 mm x 480 mm
Weight 15 kg
3.2.3 Power Distribution Subrack
Table 3-3 Technical specications
Item Specications
Maximum input current 63 A
Number of phases Single phase
Input frequency 50/60 Hz
Input voltage 220 V
Output frequency 50/60 Hz
General input 2 x 63 A/1P
UPS input 63 A/1P
UPS output 63 A/1P
UPS bypass 63 A/1P
Output branch 4 x 40 A/1P
Dimensions (H x W x D) 130 mm x 442 mm x 450 mm
3.2.4 Lithium Battery ESM-48100B1
Lithium batteries provide backup power. When the mains is normal, the UPS
charges batteries. When the mains fails, lithium batteries supply power to the UPS.
Figure 3-3 Lithium battery
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 3 System Architecture
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 22
