Procedure
Step 1 Tap Shutdown on the controller home screen.
Exercise caution because the device is still energized after it is shut down on the
controller home screen.
Step 2 Remove the cables from the T/H sensor.
After removing cables, wrap exposed terminals with insulation tape and do not
block cable labels. If cable labels are blocked, cables may be connected incorrectly
later.
Step 3 Remove the faulty T/H sensor.
Step 4 Attach the new T/H sensor to an appropriate position on the cabinet door frame
based on the site requirements.
Step 5 Reinstall the cable removed from the T/H sensor.
Before removing a T/H sensor, remember the DIP switch setting on it. When you install a
new T/H sensor, you need to set the same DIP switch setting for the new one.
----End
6.4.3.8 Replacing a Smoke Detector
Prerequisites
● Recommended tools and materials: Phillips screwdriver, insulation tape, step
ladder (2 m)
● A smoke detector needs to be replaced.
● A spare smoke detector of the same model is available and functional.
Context
The smoke detector is installed on the top of the cabinet, as shown by (1) in
Figure 6-17.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 6 O&M
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 193
