Status Messages
Analog Output Error Signals
If the CS enters into an error status all following measured value signals are
output in a specific current strength (I) or voltage (U). Please refer to chapter
"Error status" for the respective values for the current strength or voltage of
the output signal during an error status). The time coding is preserved.
Example: " " error for the SAE output signal.
4,0
I (mA)
U (V)
t (ms)
4,8
Low
20,0
19,2
High High
Low
4,5
4,3
4,1
19,7
19,5
300
3000
1 3 5
7
1
2
4
6
8
2,0
2,05
2,25
2,4
9,85
9,75
2,15
9,6
0,0
19,8
10,0
9,9
Time
Signal Variable
Signal duration
per pulse
in ms
Current (I) / Voltage (U)
1 Identifier SAE A 300 High / Low
2
Measured
value
SAE A 3000
4.4 mA / 2.2 V
3 Identifier SAE B 300 High / Low / High / Low
4
Measured
value
SAE B 3000
4.4 mA / 2.2 V
5 Identifier SAE C 300 High / Low / High / Low / High / Low
6
Measured
value
SAE C 3000
4.4 mA / 2.2 V
7 Identifier SAE D 300 High / Low / High / Low / High / Low / High / Low
8
Measured
value
SAE D 3000
4.4 mA / 2.2 V
ContaminationSensor CS1000
en(us)
Page 109 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
