Hydac CS1000 series User Manual

Operating the CS1x2x sensor using the keypad
- Set output signal on analogue output
The set measured variable is output via the analog output (see page 66).
Set analog output -
output signal
Description
NAS Maximum
NAS class 2/5/15/25 (Code)
NAS class+Temp. (coded)
Fluid temperature
ISO for HDA 5500
NAS or SAE for HDA 5500
ISO Code 2
ISO Code 5
ISO Code 15
ISO 3-digit (coded)
ISO 3-digit+Temp. (coded)
NAS class 2-5 µm
NAS class 5-15 µm
NAS class 15-25 µm
NAS class >25 µm
Discard changes
and exit
Save changes and
exit
ContaminationSensor CS1000
en(us)
Page 56 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
