Using switching output
Using switching output
You can use the switching output in the modes described below. For a further
description of the measurement modes, see page 31.
Mode M1: Continuous measurement
Purpose:
Measurement only
Function:
Continuous measurement of cleanliness class Switching
function only for "Device ready".
Mode M2: Continuous measurement and switching
Purpose:
Continuous measurement and controlling of signal lamps etc.
Function:
Continuous measurement of solid particle contamination,
continuous monitoring of programmed limit values. The
switching output is enabled and switches on the monitoring
display or alarm on site.
Mode M3: Filter to cleanliness class and stop
Purpose:
For cleaning up a hydraulic reservoir
Function:
Control of a filter unit, continuous measurement of solid particle
contamination. If pre-programmed cleanliness level is achieved
5 times in sequence, the pump is stopped.
Mode M4: Filter to continuously monitor cleanliness class
Purpose:
Establish continuous monitoring of cleanliness class between
min/max limit values
Function:
Control of a filter unit, continuous measurement of solid particle
contamination. If min./max. limit values are pre-programmed,
the CS switches the filtration unit on/off to maintain the
cleanliness within the limit value range.
Load the switching output with a maximum of 2 A and 30 V DC.
Mode " ": Single measurement
Purpose:
Perform a single measurement and "stop" the result.
Function:
Single measurement of solid particle contamination without
switching functions. Switching function only for "Device ready".
ContaminationSensor CS1000
en(us)
Page 63 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
