Hydac CS1000 series User Manual

Operating the CS1x2x sensor using the keypad
Measuring Menu (CS12xx)
During measurement operation, you can perform the following settings:
Selection
To do
Start the measuring menu
Press the key.
Exit the measuring menu
without saving
Scroll through to and press the
key.
If a key is not pressed within 30 seconds,
the system jumps back automatically.
Save and exit the measuring
menu
Scroll through to and press the
key.
Measuring Menu:
Description
Set display
Configure switching output
Set analog output - output
signal
Discard changes and exit
Save changes and exit
ContaminationSensor CS1000
en(us)
Page 45 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
