Reading the analog output
ISO Code, 3-digit
The ISO code signal consists of 3 measured values (>4µm
(c)
/ >6µm
(c)
/
>14µm
(c)
) which are transmitted time-coded.
4,0
4,1
I (mA)
1
3
2
4
6
2
5
1
U (V)
t (ms)
4,8
19,2
High
High
Low
Low
300
3000
3000
3000
9,75
19,5
2,15
2,05
2,0
9,85
19,7
0,0
19,8
9,9
Time
Variable
Signal duration
per pulse
in ms
Current (I) / Voltage (U)
1 Identifier >4µm
(c)
300 High / Low
2
Measured
value
>4µm
(c)
3000
Current/Voltage for measured value
3 Identifier >6µm
(c)
300 High / Low / High / Low
4
Measured
value
>6µm
(c)
3000
Current/Voltage for measured value
5 Identifier >14µm
(c)
300 High / Low / High / Low / High / Low
6
Measured
value
>14µm
(c)
3000
Current/Voltage for measured value
ContaminationSensor CS1000
en(us)
Page 79 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
