Reading the analog output
Using the analog output, the measured values can be issued in time-coded
form. The transfer, depending on the settings, takes up to 52 seconds to
complete and once the measuring time is up, that is, when there is a new
measured value, will not be cancelled.
This means that with a CS with Display on the screen, there may be a
different measured value than on a connected controller.
Depending on CS model, the analogue output is available as a 4 – 20 mA or
2 – 10 V signal.
You can recognize the type of analog output from the model code of the
sensor.
Observe the design of the analog output in the order. It is not possible to
internally change the analog output over later.
In the measuring menu, select one of the following signals for the analog
output:
• SAE Class according to AS 4059
• ISO Code acc. to ISO 4406:1999
• ISO Code acc. to ISO 4406:1987
• NAS Class according to NAS 1638
• Fluid temperature
ContaminationSensor CS1000
en(us)
Page 66 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
