Hydac CS1000 series User Manual

Annex
Definition acc. to SAE
Particle count (absolute) larger than a defined particle size
Example: Cleanliness class acc. to AS 4059=6
The maximum permissible particle count in the individual size ranges is bold-
faced in the table on page 126.
Cleanliness class to AS 4059= 6B
Size B particles may not exceed the maximum number indicated for code 6:
6 B = max. 19,500 particles > 5 µm in size
Specifying a cleanliness code for each particle size
Example: Cleanliness class to AS 4059= 7 B / 6 C / 5 D
Cleanliness class
Max. particles / 100 ml
Size B ( > 5 µm / > 6 µm
(c)
)
38,900
Size C ( > 15 µm / > 14 µm
(c)
)
3460
Size D ( > 25 µm / > 21 µm
(c)
)
306
Specifying highest measured cleanliness class
Example: Cleanliness class acc. to AS 4059= 6 B – F
The 6 B – F specification requires a particle count in size ranges B – F. The
respective particle concentration of cleanliness class 6 may not be exceeded
in any of these ranges.
ContaminationSensor CS1000
en(us)
Page 127 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
