Setting the measuring mode
Setting the measuring mode
Once the sensor is switched on or supplied with power, it automatically runs
in the measuring mode that has been set.
Mode M1: Continuous measurement
Application:
Stand-alone sensor
Data output:
Display & RS485 & analog output
Purpose:
Measurement only
Function:
Continuous measurement of cleanliness class Switching
function only for "Device ready".
Mode M2: Continuous measurement and switching
Application:
Stand-alone sensor with alarm standby display
Data output:
Display & RS485 & analog output & switching output
Purpose:
Continuous measurement and controlling of signal lamps
etc.
Function:
Continuous measurement of solid particle contamination,
continuous monitoring of programmed limit values. The
switching output is enabled and switches on the
monitoring display or alarm on site.
Mode M3: Filter to cleanliness class and stop
Application:
Controlling a filter unit
Data output:
Display & RS485 & analog output & switching output
Purpose:
For cleaning up a hydraulic reservoir
Function:
Control of a filter unit, continuous measurement of solid
particle contamination. If pre-programmed cleanliness
level is achieved 5 times in sequence, the pump is
stopped.
Load the switching output with a maximum of 2 A and
30 V DC.
ContaminationSensor CS1000
en(us)
Page 31 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
