Hydac CS1000 series User Manual

Technical Data
Technical Data
General data
Mounting position
Any (recommended: vertical position)
Self diagnostics
continuously with error indication
via status LED and display
Display (only CS 1x2x)
LED, 6 digits, in 17 segment format
Measured variables
CS 12xx
ISO / SAE
CS 13xx
ISO / SAE / NAS
Measurement range
Display
ISO 9/8/7 … ISO 25/24/23
SAE 0 … SAE 14
NAS 0 … NAS 14
Calibrated
ISO 13/11/10 … ISO 23/21/18
SAE 2 … SAE 12
NAS 2 … NAS 12
Accuracy
± ½ cleanliness class in the
calibrated range
Service variables
Flow
Status
Out
mA or VDC depending on model
Drive
%
Temp
°C and °F
Permitted ambient temperature
range
-30 … 80 °C / -22 … 176 °F
Permitted storage temperature
range
-40 … 80 °C / -40 … 176 °F
Permitted relative humidity
max. 95%, non-condensing
Material of seal
CS 1xx0
FKM
CS 1xx1
EPDM
Protection class
III (low voltage protection)
Protection class
IP 67
(only with screw-lock connectors)
Weight
≈ 1.3 kg
ContaminationSensor CS1000
en(us)
Page 118 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
