Hydac CS1000 series User Manual

Operating the CS1x2x sensor using the keypad
PowerUp Menu
You can carry out the basic settings for operation of the sensor in the
PowerUp menu.
Selection
To do
PowerUp Start menu
Press any key while the supply voltage to
the sensor is switched on / generated.
PowerUp Exit the menu without
saving
Scroll through to and press
the key.
If a key is not pressed within 30 seconds,
the system jumps back automatically.
PowerUp Exit the menu with
Save
Scroll through to and press the
key.
PowerUp
Menu:
Description
Select measurement mode
Set measuring duration
Set pump protection time
Set bus address
Select calibration
(only 13xx)
Set history memory
Reset CS to factory default
settings
Discard changes and exit
Save changes and exit
For internal use only
ContaminationSensor CS1000
en(us)
Page 41 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
