Ethernet option
The Ethernet option displays the operational states of the Ethernet port and its
media access control (MAC) address.
When a cluster is created, only one node’s Ethernet port becomes active for cluster
configuration. If the node which has the active port fails, then another node in the
cluster opens its Ethernet port and gains configuration access to that cluster.
Active The cluster is accessible through this port.
Inactive
The port is operational, but it cannot access the cluster. This port can be
used to access the cluster if the cluster’s active port fails.
Failed The port is not operational.
Press
the right button to display the MAC address of the Ethernet port.
Fibre channel port-1 through 4 option
The fibre channel port-1 through 4 options display the operational status of the
fibre-channel ports.
Active The port is operational and can access the fibre-channel fabric.
Inactive
The port is operational but cannot access the fibre-channel fabric. One of
the following conditions caused this result:
v The fibre-channel cable has failed
v The fibre-channel cable is not installed
v The device that is at the other end of the cable has failed
Failed The port is not operational because of a hardware failure.
Not installed
This port is not installed.
To
display the current fibre-channel port speed, press and hold the down button,
press and release the select button, and release the down button. For the SAN
Volume Controller 2145-4F2 or the SAN Volume Controller 2145-8F2, this action
also allows you to change the fibre-channel port speed of a node that is not
participating in a cluster, by pressing the up or down buttons.
Select language? option
The language displayed can be changed from the menu.
The Select language? option allows you to change the language that is displayed
on the menu. Figure 106 shows the Select language? option sequence.
Deutsch
Portugu s (Brazil)ê
English
Fran aisç
Select Language?
Select
Figure 106. Select language? menu sequence
150 IBM System Storage SAN Volume Controller: Hardware Installation Guide
