IBM 2145UPS-1U User Manual

2145 UPS-1U ports not used
The 2145 UPS-1U is equipped with ports that are not used by the SAN Volume
Controller and have not been tested. Use of these ports, in conjunction with the
SAN Volume Controller or any other application that may be used with the SAN
Volume Controller, is not supported. Figure 9 shows the 2145 UPS-1U ports that
are not used.
1
USB interface port
2
Network ports
3
Load segment receptacles
Hardware locations for the 2145 UPS-1U
1
Frame assembly
2
Battery pack assembly
svc00147
ON
OFF
121 2
svc00209
1
2
3
Figure 9. Ports not used by the 2145 UPS-1U
svc00002
1
2
3
4
Chapter 4. Using the 2145 UPS-1U 27
