v SAN Volume Controller Console
v Adobe Reader
The following Web site provides the current list of supported software versions:
http://www.ibm.com/storage/support/2145
After the master console hardware is installed, the customer must configure the
software to meet their requirements.
Preparing your master console hardware option environment
If the master console hardware option is included with the SAN Volume
Controller, ensure that your physical site meets the installation requirements for
the master console hardware and the console monitor kit.
Server dimensions and weight
The following tables provide the physical characteristics and the environmental
requirements for the master console hardware option:
Height Width Depth Maximum Weight
44 mm
(1.7 in.)
480 mm
(18.9 in.)
426 mm
(16.8 in.)
12.7 kg
(28 lb)
Server AC and input-voltage requirements
Power Supply Electrical Input
203 watt (110 or 220 V ac auto-sensing) Sine-wave input (47–63 Hz) required
Input voltage low range:
Minimum: 100 V ac
Maximum: 127 V ac
Input voltage high range:
Minimum: 200 V ac
Maximum: 240 V ac
Input kilovolt-amperes (kVA),
approximately:
Minimum: 0.0870 kVA
Maximum: 0.150 kVA
Server environment
Environment Temperature Altitude Relative Humidity
Server On 10° to 35°C
(50°F to 95°F)
0 to 914 m
(2998.0 ft)
8% to 80%
Server Off -40°C to 60°C
(-104°F to 140°F)
Maximum:
2133 m
(6998.0 ft)
8% to 80%
Server heat output
Approximate heat output in British thermal units (Btu) per hour:
v Minimum configuration: 87 watts (297 Btu)
32 IBM System Storage SAN Volume Controller: Hardware Installation Guide
|
|
|
|
|
|
