Appendix B — Default Settings
128 PM23c, PM43, and PM43c Mid-Range Printer User Manual
Default Configuration
Use this appendix to view the default settings on the printer. The
following tables list the default settings for the PM23c, PM43, and
PM43c printers. If you restore the printer to factory default settings, it
will use the values listed here. The order of the settings reflects the
organization of the printer web page and Main Menu.
Serial Port Settings
This section describes the serial port settings. To view these settings:
• From the printer Main Menu, select Settings > Communications
> Serial > COM1.
• From the printer web page, click the Configure tab,
Communications > Serial.
Note: These settings are not accessible unless the printer has a serial
connection to a PC.
Serial Port Settings
Setting Description Default
Baud Rate Transmission speed in bits per second
(bps) for the serial port.
115200
Data Bits Number of bits that define a character or
byte.
8
Parity Specifies how the printer checks the
integrity of the transmitted data.
None
Stop Bits Number of bits sent at the end of every
character to allow the receiving signal
hardware to detect the end of a character
and to resynchronize with the character
stream.
1
Hardware Specifies if hardware flow control
(RTS/CTS) is used to manage the rate of
data transmission between the device and
the host.
Disable
