Chapter 1 — About the Printer
6 PM23c, PM43, and PM43c Mid-Range Printer User Manual
About the Print Button
The blue button on the front panel is the Print button. All models of
printer have a blue Print button. Use the Print button to feed media,
pause print jobs, and print. Use this table to understand the functions
of the Print button.
Print Button Behavior
State of the Printer Printer Behavior
Starting Press the Print button during startup to enter
Calibration mode or to restore defaults if the
printhead is lifted.
Ready Press the Print button to advance media.
Press and hold the Print button for more than two
seconds to perform a test feed.
If the print key feature is enabled (on), the printer
reprints the last print job.
Printing Press the Print button to stop or pause printing. The
printer will stop after it completely prints one label.
Paused Press the Print button to resume printing.
Error Press the Print button to advance media if possible.
