Position Coil Locating
Ring,
PIN
334994, over
machined bosses
on
the ignition plate. Push the
locating
ring
in
toward the component to
be
installed. Hold the
ring
in
place and pull the com-
ponent out toward the
ring.
Tighten screws
to
15
to
22
in.
Ibs.
(1.6 to 2.4 N.m).
Do
this step for each
component
installed.
IGNITION COIL
Removal
Twist
and
remove
cover.
Remove the spark plug
and primary leads
from
the ignition coils.
IMPORTANT: Make a note of the fastener and
washer
locations before removing any screws.
2
9.9/15 Model
1. Fiber washer
2. Ignition coil ground strap
3. Starwasher
4. Stop switch ground lead
'--_---3
1'=:------
2
1
2
3
/J-_----
4
DR5055
IGNITION
IGNITION COIL
4
----~~~~~~~-2
1-----3
2
5
4
----~~~~~~~------2
-------3
tr------2
1nIt..,j---'11IIrIl
---~~~n~~----------4
25/30 Model
DR5741
1. Fiber washer
2. Flat washer
3.
Ignition coil ground strap
4. Starwasher
5. J-clamp
6. Stop switch ground lead
Remove the screws, coil, and washers.
Installation
Assemble the correct sequence of washers and
locate the ignition coil
on
the powerhead. Install
screws and torque to
48
to
96
in.
Ibs.
(5.4 to 10.8
N·m).
Apply a light coating of Electrical Grease to the
ribbed portion of the spark
plug ceramics and
to
the openings of each of the spark plug lead cov-
ers.
Install the spark plug leads.
Apply
a light coating of Electrical Grease to the
opening of each primary
lead cover and install the
covers. Observe proper wire routing and ignition
timing. Orange/blue primary lead must
be
con-
nected to the number 1 ignition
coil.
I
E
o
o
:;j
)(
~
Qj
~
ii
135
~
