Rev. 2.0

Maintenance Guide

9-6

40000589

LIFTER CYLINDER SHAFT

PA630750300

AIR CYLINDER

SM1062052TP

Hexagon socket head cap flat screw

40093854

CYLINDER_SCREW_M8_L=125

PC015203000

SPEED CONTROLLER
