Connecting the 3G USB Modem on the USB Modem Extension Cable-Mount
The 3G USB modem is secured with a USB protection cover as shown in Figure 22 on
page 98.
Figure 22: 3G USB Modem with USB Protection Cover
Table 38 on page 98 lists the components of the 3G USB modem with USB protection
cover.
Table 38: 3G USB Modem with USB Protection Cover Components
ComponentNumber
USB mount top cover1
USB modem2
USB mount (magnetic/non-magnetic)3
USB mount base4
Lock5
Copyright © 2012, Juniper Networks, Inc.98
SRX110 Services Gateway Hardware
