Table 27: RJ-45 Connector Pinouts for the Services Gateway Console
Port (continued)
DescriptionSignalPin
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Related
Documentation
Connecting and Organizing the SRX110 Services Gateway Interface Cables on page 102•
• Interface Cable and Wire Specifications for the SRX110 Services Gateway on page 71
RJ-11 Connector Pinouts for the SRX110 Services Gateway
Table 28 on page 74 describes the RJ-11 connector pinouts for the VDSL2 port.
Table 28: RJ-11 Connector Pinouts
SignalPin
No connect1
No connect2
RJ P –Ring3
RJ N –Tip4
No connect5
No connect6
Related
Documentation
• Connecting and Organizing the SRX110 Services Gateway Interface Cables on page 102
• Interface Cable and Wire Specifications for the SRX110 Services Gateway on page 71
