Juniper SRX110 User Manual

Table 15: Profiles Supported on the Integrated VDSL2
Interface (continued)
Data Rate (Mbps)Profile
10017a
Auto-negotiated (based on profile)Auto
Related
Documentation
SRX110 Services Gateway Integrated VDSL2 Interface Overview on page 25•
• SRX110 Services Gateway Integrated VDSL2 Interface LEDs on page 27
• Configuring the Integrated VDSL2 Interface on the SRX110 Services Gateway on page 28
SRX110 Services Gateway Integrated VDSL2 Interface LEDs
The integrated VDSL2 interface has two LEDs. Table 16 on page 27 describes the LED
states.
Table 16: Integrated VDSL2 LEDs
DescriptionStateColorLED
Indicates that the VDSL2 interface link is up.OnGreenSYNC
Indicates training is in progress and there is
no connection to CO.
NOTE: Training refers to the negotiation of
the best mode for a DSL connection.
Blinking
Indicates that interface has not yet booted
up.
Off
Indicates that traffic is passing through.BlinkingGreenTX/RX
Indicates that it is an invalid state.On
Indicates that no traffic is passing through.Off
Related
Documentation
SRX110 Services Gateway Integrated VDSL2 Interface Overview on page 25•
• SRX110 Services Gateway LEDs on page 13
• Configuring the Integrated VDSL2 Interface on the SRX110 Services Gateway on page 28
27Copyright © 2012, Juniper Networks, Inc.
Chapter 4: SRX110 Services Gateway Integrated VDSL2 Interface
