Figure 2: SRX110 Services Gateway with 3G and VDSL2
(VDSL/ADSL-ISDN)
NOTE: SRX110B-VA and SRX110B-VB do not support security features such
as unified threat management and intrusion detection and prevention.
Table 5 on page 8 provides information on the physical specifications of the SRX110
Services Gateway.
Table 5: SRX110 Services Gateway Specifications
ValueSpecification
1.7 in. (4.4 cm)Chassis height
11 in. (28 cm)Chassis width
8.4 in. (21.3 cm)Chassis depth
4.3 lb (1.962 kg)Chassis weight
24 WAverage power consumption
No performance degradation to 10,000 ft (3048 m)Altitude
5% to 90%, noncondensingRelative humidity
Normal operation ensured in temperature range of 32°
F (0° C) to 104° F (+40° C)
Nonoperating storage temperature in shipping container:
–40° F (–40° C) to 158° F (70° C)
Temperature
99 BTU/hourMaximum thermal output
< 15 dB(A) or less per EN ISO 7779Noise level
Copyright © 2012, Juniper Networks, Inc.8
SRX110 Services Gateway Hardware
