Kubota L2800 Workshop Manual

1-S15
L2800, L3400, WSM
ENGINE
Fan Belt Damage and Wear
1. Check the fan belt for damage.
2. If the fan belt is damaged, replace it.
3. Check if the fan belt is worn and sunk in the pulley groove.
4. If the fan belt is nearly worn out and deeply sunk in the pulley
groove, replace it.
W1035758
(6) Radiator
Thermostat Valve Opening Temperature
1. Suspend the thermostat in the water by a string with its end
inserted between the valve and seat.
2. Heating the water gradually, read the temperature when the
valve opens and leaves the string.
3. Continue heating and read the temperature when the valve
opens approx. 6 mm (0.236 in.).
4. If the measurement is not within the factory specifications,
replace the thermostat.
W1035849
(A) Good (B) Bad
Thermostat’s valve
opening temperature
Factory spec.
69.5 to 72.5 °C
157.1 to 162.5 °F
Temperature at which
thermostat completely
opens
Factory spec.
85 °C
185 °F
KiSC issued 08, 2007 A
Tractor Manuals Scotland - Please Do Not Copy
Tractor Manuals Scotland

Kubota L2800 Specifications

General

Engine Type	Diesel
Engine Power	28 hp
Type	Compact utility tractor
Rear tire size	11.2-24
PTO Horsepower	23.5 hp
Weight	2, 425 lbs
Drive	4WD
Front tire size	5.00-15 (2WD)
