Kubota L2800 Workshop Manual

2-S3
L2800, L3400, WSM
CLUTCH
2. SERVICING SPECIFICATIONS
[L2800]
W1013874
Item Factory Specification Allowable Limit
Clutch Pedal Free Travel 20 to 30 mm
0.8 to 1.2 in.
–
Pressure Plate to Adjusting Bolt Clearance 1.4 to 1.5 mm
0.055 to 0.059 in.
–
Clutch Disc Boss to Main Shaft (Travelling) Backlash
(Displacement
around Disc Edge)
–
2.0 mm
0.079 in.
Clutch Disc Disc Surface to
Rivet Top (Depth)
– 0.3 mm
0.012 in.
Diaphragm Spring Mutual Difference – 0.5 mm
0.020 in.
Pressure Plate to Straightedge Clearance – 0.2 mm
0.008 in.
Brake Pedal Shaft to Clutch Pedal Bushing
Brake Pedal Shaft
Clutch Pedal Bushing
Clearance
O.D.
I.D.
0.05 to 0.20 mm
0.002 to 0.008 in.
24.90 to 25.00 mm
0.980 to 0.984 in.
25.05 to 25.10 mm
0.986 to 0.988 in.
1.0 mm
0.039 in.
–
–
Clutch Lever O.D. 14.97 to 15.00 mm
0.589 to 0.591 in.
14.13 mm
0.556 in.
KiSC issued 08, 2007 A
Tractor Manuals Scotland - Please Do Not Copy
Tractor Manuals Scotland

Kubota L2800 Specifications

General

Engine Type	Diesel
Engine Power	28 hp
Type	Compact utility tractor
Rear tire size	11.2-24
PTO Horsepower	23.5 hp
Weight	2, 425 lbs
Drive	4WD
Front tire size	5.00-15 (2WD)
