Kubota L2800 Workshop Manual

8-S9
L2800, L3400, WSM
HYDRAULIC SYSTEM
(3) Hydraulic Pump Test Using Flow-meter (Three Point Hydraulic System)
Preparation
1. Remove the support (3) mounting screw.
2. Remove the screw (2).
3. Remove the joint shaft (1).
(When reassembling)
• Lift the universal joint so that there should be a clearance (A) of
more than 5 mm (0.19 in.) between the universal joint and
flywheel housing.
Then fit the support (3) in position.
W1019601
(1) Joint Shaft
(2) Screw
(3) Support
(A) Clearance
KiSC issued 08, 2007 A
Tractor Manuals Scotland - Please Do Not Copy
Tractor Manuals Scotland

Kubota L2800 Specifications

General

Engine Type	Diesel
Engine Power	28 hp
Type	Compact utility tractor
Rear tire size	11.2-24
PTO Horsepower	23.5 hp
Weight	2, 425 lbs
Drive	4WD
Front tire size	5.00-15 (2WD)
