Kubota L2800 Workshop Manual

6-S2
L2800, L3400, WSM
FRONT AXLE
2. SERVICING SPECIFICATIONS
2WD TYPE
W1013874
4WD TYPE
W1013973
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 2 to 8 mm
0.08 to 0.32 in.
–
Front Wheel Axial Sway Less than 5 mm
0.20 in.
–
Front Axle Rocking Force 49.0 to 117.7 N
5.0 to 12.0 kgf
11.0 to 26.5 lbs
–
Knuckle Shaft to Bushing
Knuckle Shaft
Bushing
Clearance
O.D.
I.D.
0.000 to 0.285 mm
0.00000 to 0.01122 in.
27.880 to 27.900 mm
1.09764 to 1.09842 in.
27.900 to 28.165 mm
1.09842 to 1.10886 in.
0.4 mm
0.016 in.
–
–
Front Axle Middle Boss to Front Axle Shaft
Bracket Bushing
Front Axle Middle Boss
Bushing
Clearance
O.D.
I.D.
0.000 to 0.177 mm
0.00000 to 0.00697 in.
39.938 to 40.000 mm
1.57236 to 1.57480 in.
40.000 to 40.115 mm
1.57480 to 1.57933 in.
0.3 mm
0.012 in.
–
–
Front Wheel Alignment Toe-in 2 to 8 mm
0.08 to 0.32 in.
–
Front Wheel Axial Sway Less than 5 mm
0.20 in.
–
Front Axle Rocking Force 49.0 to 117.7 N
5.0 to 12.0 kgf
11.0 to 26.5 lbs
–
Front Axle Case Boss (Front) to Bracket
Bushing
Front Axle Case Boss (Front)
Bushing
Clearance
O.D.
I.D.
0.025 to 0.160 mm
0.00098 to 0.00630 in.
49.950 to 49.975 mm
1.96653 to 1.96752 in.
50.000 to 50.110 mm
1.96850 to 1.97283 in.
0.35 mm
0.0138 in.
–
–
Front Axle Case Boss (Rear) to Bracket
Bushing
Front Axle Case Boss (Rear)
Bushing
Clearance
O.D.
I.D.
0.025 to 0.190 mm
0.00098 to 0.00748 in.
70.000 to 70.035 mm
2.75590 to 2.75728 in.
70.060 to 70.190 mm
2.75826 to 2.76338 in.
0.35 mm
0.0138 in.
–
–
