Kubota L2800 Workshop Manual

5-S2
L2800, L3400, WSM
BRAKES
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 20 to 30 mm
0.79 to 1.2 in.
–
Right and Left
(Difference)
Less than 5mm
0.20 in.
–
Brake Pedal Shaft to Bushing
Brake Pedal Shaft
Brake Pedal Bushing
Clearance
O.D.
I.D.
0.020 to 0.153 mm
0.00079 to 0.00602 in.
24.9 to 25.0 mm
0.980 to 0.984 in.
25.020 to 25.053 mm
0.98504 to 0.98634 in.
1.0 mm
0.039 in.
–
–
Brake Pedal Shaft to Support Bushing
Support Bushing
Clearance
I.D.
0.05 to 0.20 mm
0.0020 to 0.0079 in.
25.05 to 25.10 mm
0.9862 to 0.9882 in.
1.0 mm
0.039 in.
–
Cam Plate Flatness – 0.3 mm
0.012 in.
Cam Plate and Ball Height 20.9 to 21.1 mm
0.823 to 0.831 in.
20.5 mm
0.8071 in.
Brake Disc Thickness 4.6 to 4.8 mm
0.181 to 0.189 in.
4.2 mm
0.165 in.
Plate Thickness 2.54 to 2.66 mm
0.1000 to 0.1047 in.
2.1 mm
0.0827 in.
KiSC issued 08, 2007 A
Tractor Manuals Scotland - Please Do Not Copy
Tractor Manuals Scotland

Kubota L2800 Specifications

General

Engine Type	Diesel
Engine Power	28 hp
Type	Compact utility tractor
Rear tire size	11.2-24
PTO Horsepower	23.5 hp
Weight	2, 425 lbs
Drive	4WD
Front tire size	5.00-15 (2WD)
