Midas PRO1 User Manual

Mixes 269
PRO1 Live Audio System
Operator Manual
Mixes
Each input channel can send an individually controllable contribution to each of the 16
aux buses (aux sends) and eight matrix buses (mtx sends). The contributions to the
buses are controlled by mix controls that give continuous adjustment (in the range
+6dB to off). The controls in the mix fader bay include level/pan and level control
knobs, with the pan control coming into operation when the corresponding bus is stereo
linked to its neighbour.
The mix section in the channel processing area controls a bank of eight buses per
selected input channel and this layout is replicated in the GUI channel strip.
Item Description
1 Aux/matrix buttons to activate flip on the channel faders.
2 clear button, cancels flip.
3 Quick access button for assigning the mix sends to the GUI channel
processing area.
4 ON switches, switch bus assignment on/off.
5 PRE buttons; when on, signal is pre-fader.
6 After a input channel has been selected to the channel strip, level/pan and
level control knobs offer control of relative contribution levels onto the
active buses. level/pan operates odd numbered controls, while level
operates the even ones.
1
23
4
5
6
