139
CHAPTER 3 FUNCTIONS
3
3.7 Q Series-compatible Module Input Response Time Selection (I/O Response Time)
3.7 Q Series-compatible Module Input Response Time
Selection (I/O Response Time)
This function is used to change the input response time for each Q series-compatible module. The following table lists
the modules available for input response time change and selectable time settings.
The Q series-compatible modules in the table above take in external inputs within the set input response time.
Module name Type Settable time
Input module "Input"
1ms, 5ms, 10ms, 20ms, 70ms (Default: 10ms)
I/O combined module "I/O Mix"
High-speed input module "Hi Input"
0.1ms, 0.2ms, 0.4ms, 0.6ms, 1ms (Default: 0.2ms)
Interrupt module "Interrupt"
OFF
OFF
ON
ON
External input
Q series-compatible module
Input response time
To Next Page
