30
1.4 Converting a Program
Operation of a program is defined after converting its ladder.
[Compile] [Build]
The program has been converted. In the next procedure, write the program to a CPU module.
● To use a label, the program must be compiled.
GX Works2 Version 1 Operating Manual (Common)
● After modifying a program, it must be compiled.
1.5 Writing a Project to the CPU Module
Write a project to the CPU module. Note that, if the project is new, the memory ( Page 35, Section 2.1.1) needs to
be formatted first.
1.5.1 Formatting a memory
To format a memory, open the "Format PLC Memory" dialog box. In this chapter, a program memory is formatted so
that a program can be written to it.
[Online] [PLC Memory Operation] [Format PLC Memory...]
To check the capacity of the memory after formatting, open the "Online Data Operation" dialog box.
To Next Page
