APPENDICES

Appendix 1 Parameters

Appendix 1.2 PLC parameters

Appendix 1.2.7 SFC

The mode and conditions for starting an SFC program, and the output mode in the case of a block stop are set.

Item

Parameter

No.

Description Setting range Default Reference

SFC Program Start Mode

8002

Set the mode and conditions for

starring an SFC program, and

also set the output mode in case a

program block is stopped.

MELSEC-Q/L/QnA

Programming Manual (SFC)

Initial Start

MELSEC-

Q/L/QnA

Programming

Manual (SFC)

Start Conditions

8003

Autostart Block 0

Output Mode When the Block

is Stopped

8006

Turn OFF
