2.3.3 I/O number setting example
I/O number setting examples are provided as follows.
(1) Changing the number of points of an empty slot from 16 to 32
Reserve 32 points for the currently empty slot (Slot 3) so that the I/O numbers of Slot No. 4 and later do not
change when a 32-point input module is mounted there in the future.
(a) System configuration and I/O number assignment before I/O assignment setting
(b) I/O assignment
Select "32 Points" for "Points" of the slot 3 in the I/O Assignment tab of the PLC parameter dialog box. (When
"Type" is not specified, the type of the mounted module will be set.)
Input module Input module Input module
Empty
Output module Output module Output module Output module
Q38B
Q68B
Extension
1
012 45673
8 9 10 12 13 14 1511
…Slot number
…Number of I/O points
…I/O number
32
points
32
points
32
points
16
points
32
points
32
points
32
points
32
points
32
points
32
points
32
points
32
points
16
points
32
points
32
points
32
points
X00
to
X1F
X20
to
X3F
X40
to
X5F
60
to
6F
Y70
to
Y8F
Y90
to
YAF
YB0
to
YCF
YD0
to
YEF
100
to
10F
110
to
12F
130
to
14F
150
to
16F
170
to
17F
180
to
Y19F
Y1A0
to
Y1BF
Y1C0
to
Y1DF
Intelligent function
module
Intelligent function
module
Intelligent function
module
Intelligent function
module
Empty
Output module Output module Output module
