APPENDICES
A
Appendix 10 Device Point Assignment Sheet
Appendix 10 Device Point Assignment Sheet
*1 The points are determined by the system (cannot be changed). The points for the step relay can be changed to 0K for
the Universal model QCPU whose serial number (first five digits) is "10042" or later. For the Universal model QCPU
whose serial number (first five digits) is "12052" or later, a step relay can be set in increments of 1K point and up to the
following points. ( Page 465, Appendix 2)
• Q00UJCPU, Q00UCPU, Q01UCPU, and Q02UCPU: 8192 points
• Universal model QCPU other than the Q00UJCPU, Q00UCPU, Q01UCPU, and Q02UCPU: 16384 points
*2 Up to 32K points can be set for each device. However, up to 60K points can be set for each device of the internal relay
and link relay for the Universal model QCPU whose serial number (first five digits) is "10042" or later.
*3 Enter the values multiplied (or divided) by the number shown in the Size (words) column.
Device name Symbol
Numeric
notation
Number of device points
*2
Restriction check
Points Range
Size (words)
*3
Points (bits)
*2
Input relay
*1
X Hexadecimal 8K (8192) X0000 to X1FFF
/16
512
×
1
8192
Output relay
*1
Y Hexadecimal 8K (8192) Y0000 to Y1FFF
/16
512
×
1
8192
Internal relay M Decimal K ( ) M0 to
/16 ×1
Latch relay L Decimal K ( ) L0 to
/16 ×1
Link relay B Hexadecimal K ( ) B0000 to
/16 ×1
Annunciator F Decimal K ( ) F0 to
/16 ×1
Link special relay SB Hexadecimal K ( ) SB0000 to
/16 ×1
Edge relay V Decimal K ( ) V0 to
/16 ×1
Step relay
*1
S Decimal 8K (8192) S0 to S8191
/16
512
×
1
8192
Timer T Decimal K ( ) T0 to
×
2
Retentive timer ST Decimal K ( ) ST0 to
×
2
Counter C Decimal K ( ) C0 to
×
2
Data register D Decimal K ( ) D0 to
×
1
Link register W Hexadecimal K ( ) W0000 to
×
1
Link special register SW Hexadecimal K ( ) SW0000 to
×
1
Total
(29696 or less) (65536 or less)
