Appendix 1 Parameters

Appendix 1.2 PLC parameters

Appendix 1.2.11 Built-in Ethernet port setting

Parameters required for using the built-in Ethernet port are set.Note Appx.3

Note Appx.3

The Universal model QCPUs other than the Built-in Ethernet port QCPU do not have any Ethernet port.
