461

APPENDICES

Appendix 1 Parameters

Appendix 1.3 Network Parameters

Appendix 1.3.4 Ethernet setting

Network parameters for Ethernet are set.

Item Parameter No. Description Setting range Default Reference

Number of modules on Ethernet

9000

Set Ethernet network

parameters.

Refer to the manual for the

Q series-compatible

Ethernet.

Start I/O No.

9N00

Network No.

Group No.

Station No.

Operation Setting

Initial Setting

9N01

Open Setting

9N02

Router Relay Parameter

9N03

Station No.<->IP Information

9N05

FTP Parameters

9N06

E-mail Setting

9N07

News Setting

9N08

Interrupt Settings

9N09

Valid Module During Other Station Access

5001

Routing Parameters

9N04
