334
CHAPTER 4 DEVICES
This chapter describes the devices that can be used in the CPU module.
4.1 Device List
The following table shows the devices used in the CPU module and applicable ranges.
(1) Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU
Classification Type Name
Default
Parameter-
set range
Reference
Point Range
Internal user
device
Bit
device
Input 8192 X0 to X1FFF Hexadecimal
Can be
changed
within 29K
words.
*3
Page 346,
Section 4.2.1
Output 8192 Y0 to Y1FFF Hexadecimal
Page 348,
Section 4.2.2
Internal relay 8192 M0 to M8191 Decimal
Page 349,
Section 4.2.3
Latch relay 8192 L0 to L8191 Decimal
Page 350,
Section 4.2.4
Annunciator 2048 F0 to F2047 Decimal
Page 351,
Section 4.2.5
Edge relay 2048 V0 to V2047 Decimal
Page 355,
Section 4.2.6
Step relay 8192 S0 to S8191 Decimal
Page 358,
Section 4.2.9
Link relay 8192 B0 to B1FFF Hexadecimal
Page 356,
Section 4.2.7
Link special relay 2048 SB0 to SB7FF Hexadecimal
Page 357,
Section 4.2.8
Word
device
Timer
*1
2048 T0 to T2047 Decimal
Page 358,
Section 4.2.10
Retentive timer
*1
0 (ST0 to ST2047) Decimal
Counter
*1
1024 C0 to C1023 Decimal
Page 367,
Section 4.2.11
Data register 12288 D0 to D12287 Decimal
Page 371,
Section 4.2.12
Link register 8192 W0 to W1FFF Hexadecimal
Page 372,
Section 4.2.13
Link special
register
2048 SW0 to SW7FF Hexadecimal
Page 374,
Section 4.2.14
To Next Page
