3.11 Monitor Function
3.11 Monitor Function
Programs and device data of the CPU module, and intelligent function module status can be read from a programming
tool using this function.
: Available, : Available with restrictions, × : Not available
*1 This includes a ladder monitor, device batch monitor, entry data monitor, entry ladder monitor and local device monitor.
*2 Availability depends on the version of the CPU module. ( Page 465, Appendix 2)
(1) Monitor request timing and displayed data
The CPU module processes monitor requests from a programming tool during END processing. For this reason,
the data in the CPU module at the time of END processing will be displayed in the programming tool.
(2) Monitor with monitor condition settings
By setting a monitor condition in a programming tool during debugging, the program operation status in the CPU
module can be monitored under the specified condition. Also, by setting a monitoring stop condition, a monitoring
status can be held under the specified condition.
(3) Local device monitor
If multiple programs are executed and local devices are used, data in local devices of each program can also be
monitored.
Monitor function
Availability
Reference
Q00UJ
CPU
Q00UCPU,
Q01UCPU
Q02UCPU
QnUD(H)
CPU
Built-in
Ethernet
port QCPU
Monitor
*1
Operating manual for
the programming tool
used
Monitor condition setting × ×
*2 *2
Page 146, Section
3.11.1
Local device monitor/test ×
Page 151, Section
3.11.2
External input/output forced on/off
*2 *2
Page 154, Section
3.11.3
Executional conditioned device test
*2 *2
Page 159, Section
3.11.4
