CHAPTER 3 FUNCTIONS

3.10 Intelligent Function Module Switch Setting

Switches of a Q series-compatible intelligent function module or an interrupt module can be set in a programming tool.

(1) Writing the switch settings

The switch settings will be written from the CPU module to each intelligent function module and interrupt module

when:

• the CPU module is powered off and then on, or

• the CPU module is reset.

Programming tool

1) Write the

settings.

The settings are written when the CPU module

is powered off and then on or reset.
