26
CHAPTER 1 BASIC PROCEDURE FOR
PROGRAMMING
This chapter describes the basic procedure for programming.
1.1 System Configuration Example
The following system configuration is used for description throughout this chapter.
* Wiring of the power supply module and I/O modules are omitted in this illustration.
Creating programs
Create programs.
( )
Save the projects.
( )
Check column
Start
Creating projects
Create projects with GX Works2.
( )
Converting programs
Convert created programs into ones that can be
processed by the CPU module.
( )
Writing projects
Debug the programs using the monitoring function.
( )
Checking operations
End
Write the projects to the CPU module.
For the first use of the CPU module,
format the memory beforehand.
( )
Saving projects
Page 27, Section 1.2
Page 34, Section 1.7
Page 28, Section 1.3
Page 30, Section 1.4
Page 30, Section 1.5
Page 32, Section 1.6
CPU module (Q03UDCPU)
Power supply module (Q62P)
GX Works2
Input module (QX42)
Output module (QY42P)
USB connection
To Next Page
