3
Technical Specifications
Item ITK-24CG-1
Display LCD 4.3 inch Color (16777216 colors) TFT, with Backlight
LCD Color Color (16.77milion color)
Programmable Key 24 Keys
Fixed Feature Key 13 (Hold, Transfer, Speaker, Recall, Feature, Answer, Mic, Menu, 4 Cursor key, Enter)
Backlight LCD and digit key (lit for 10 seconds when operating)
Soft Key 4 Keys
Directory 1000 Records
Call History Outgoing Call: 50 records and Incoming Call: 50 records
XML Browser Available
Handsfree Standard equipment (Full-duplex)), Wide-band
Headset
Available (HW510 (A10) / HW251N (A10) / WT100 (APN-91) / Voyager Legend CS
(APN-91) / W710(APD-80) / W710(APN-91)
LAN Interface
2-port, 10BASE-T/100BASE-TX/1000BASE-T, Full-duplex/Half-duplex, Auto
Negotiation/Fixed (Except 1000BASE-T)
Voice CODEC G.711 (µ-law, A-law), G.729a, G.722
IP Address Setting Sets via DHCP server/Sets Statically
QoS ToS (IP Precedence, Diffserv)
VLAN Tag VLAN (IEEE802.1Q/p), LLDP-MED, DHCP
Security
IEEE802.1x authentication (EAP-MD5, EAP-TLS), IEEE802.1x authentication support
(EAPoL Forwarding) on the PC port via switch at a high hierarchy level, SIP&RTP
Encryption, HTTPS (Web Programming/Download), VPN (L2TP/IPsec (IPv4)
Power Supply
Central Power Supply = IEEE802.3at Type1 (IEEE802.3af compatible)
Local Power Supply = AC Adapter (Optional)
Power Consumption Max: Approximately 4.2W, Standby; Approximately 2.2W (without optional connection)
Download
Boot and Program / Config /Ringing Tone / Music on Hold / Wallpaper / Voice
Confirmation Tone
Adapter and
Accessory (Optional)
Ancillary Device Adapter (ADA) Wall Mount unit (WM) / Line Key Unit (8LK) / Directory
Card /60-button DSS / Numbered Keypad
Terminal Color Black / White
Dimension (WxDxH) 181(W) × 254(D) × 152(H) [mm] / 7.12(W) x 10(D) x 5.98 (H) [in]
Weight 1.0 Kg / 2.20 lbs
Environmental
Temperature range = 0° to 40°C / 32°F to 104°F (Ambient temperature range = -20°C to
60°C / 68°F to 140°F)
Humidity = 10% to 90% RH (non-condensing)
