SETTING ITEMS (ADMIN)
- 278 -
2
1
3
4
5
6
7
Memo
• Settings required for IPsec such as entry of IPsec policies
can be performed from TopAccess. For details, refer to the
TopAccess Guide “Chapter 8: [Administration] Tab
Page”.
Note
• [IPsec] is available only when the IPsec Enabler is installed.
Checking the network
Two functions are available for checking the network status:
ping and traceroute.
The ping function allows you to check the connection status
between this equipment and the servers on the network. And,
the traceroute function allows you to view and check the
network path to the desired server.
1
On the NETWORK CHECK screen, select
the server you want to check, and press
[ping] or [TRACEROUTE].
The check result is displayed.
Memo
• There are two ways to select the server you want to
check.
To select the desired server from the server list
displayed on the touch panel:
Checkable servers and supported protocols are as
follows.
- Primary DNS server (IPv4/IPv6)
- Secondary DNS server (IPv4/IPv6)
- Primary WINS server (IPv4)
- Secondary WINS server (IPv4)
- SMTP server (IPv4/IPv6)
- POP3 server (IPv4/IPv6)
- Primary SNTP server (IPv4/IPv6)
- Secondary SNTP server (IPv4/IPv6)
-LDAP server 1
-LDAP server 2
-LDAP server 3
-LDAP server 4
-LDAP server 5
- Remote server 1
- Remote server 2
To designate the desired server manually:
Enter the server name, IPv4 address, or IPv6 address
manually. When you press the Manual Input field, the on-
screen keyboard is displayed.
For details of the on-screen keyboard, see the following
page:
 P.320 "On-screen keyboard"
Note
• When you have entered a WINS name for the network
path of the remote server 1/2 in TopAccess “Save as
file Setting”, you will not be able to perform network
check on those servers by selecting them from the
server list. In this case, designate the IP address of the
remote server 1/2 manually to perform the network
check.
Item name Description
POLICY NAME The name of the currently applied
IPsec policy is displayed.
ENABLE Press this button to enable IPsec
communication.
DISABLE Press this button to disable IPsec
communication.
FLUSH
CONNECTIONS
Press this button to manually clear
(flush) the current IPsec session and
start a new session when the key
currently used for IPsec
communication has leaked or a
security violation has occurred.
FACTORY DEFAULT Press this button to reset the IPsec
settings back to the factory defaults.
When you press this button, a
confirmation message is displayed.
