PLC Link Connections

FQ2 User’s Manual

331

Connecting through Ethernet

● Expression Setting Example

This example registers an expression to output the following inspection results for data 0.

Inspection item: 0 Search

Parameters to output: Position X, Position Y, Reference SX, and Reference SY

Multi-point output setting: Multi-point output Check Box selected, Count = 4

Output Results

The expression that is registered for data 0 assigns the data for 16 items (64 bytes) in the output area as shown

below.

Output area data Assigned data

Output data 0 (4 bytes) I0.X[0] (Position X 1st point)

Output data 1 (4 bytes) I0.Y[0] (Position Y 1st point)

Output data 2 (4 bytes) I0.SX[0] (Reference SX 1st point)

Output data 3 (4 bytes) I0.SY[0] (Reference SY 1st point)

Output data 4 (4 bytes) I0.X[1] (Position X 2nd point)

Output data 5 (4 bytes) I0.Y[1] (Position Y 2nd point)

Output data 6 (4 bytes) I0.SX[1] (Reference SX 2nd point)

Output data 7 (4 bytes) I0.SY[1] (Reference SY 2nd point)

Output data 8 (4 bytes) I0.X[2] (Position X 3rd point)

Output data 9 (4 bytes) I0.Y[2] (Position Y 3rd point)

Output data 10 (4 bytes) I0.SX[2] (Reference SX 3rd point)

Output data 11 (4 bytes) I0.SY[2] (Reference SY 3rd point)

Output data 12 (4 bytes) I0.X[3] (Position X 4th point)

Output data 13 (4 bytes) I0.Y[3] (Position Y 4th point)

Output data 14 (4 bytes) I0.SX[3] (Reference SX 4th point)

Output data 15 (4 bytes) I0.SY[3] (Reference SY 4th point)

The inspection results will be output according to the sorting method that is set for multi-point output for the inspec-

tion item.

LPR(0,I0.C

I0.X,I0.Y,I0.SX,I0.SY)

Start_number

Number_of_data

(Detection count)

data_A, data_B...data_dFunction

Note
